72volt 42kw Peak Power: 35000W, Max Torque: 52Nm,
Voltage Range: 48v - 104v
Max Stable Rotor RPM: 13000RPM
Motor Configuration: 10 Poles and 12 Slots
Winding Type: Dual Y Parallel Connection
Stator and Rotor Stack Thickness: 60mm
Sensing Method: NJDC 605 Encoder
Kv Value: 95Kv
Rated Power: Air Cooled: 13600W
Max Phase Current: 900A
Rated Phane Current (continuous run): 500A (28Nm)
Waterproofing: IP67
Colour Options: Black/Red/Blue/Gold/Purple
Weight: 12.2kg
Current Type: Dc
Maximum RPM: 10001 RPM - 15000 R
Mounting Style: Clamp-On
Peak Torque: 0 Nm - 500 Nm
Type: Drivetrain Motor
Compatible for Surron lbx, Rerode, 79bike, Talaria, Eridepro
All motors come with 12 months warranty
